INN-A1-CPUSD-P4

Edge Controller

New-generation edge control & intelligent interconnection gateway

INN-A1-CPUSD-P4 is a programmable edge controller that replaces a PLC, an IoT gateway and a remote O&M module in a single device. It supports IEC 61131-3-compliant PLC programming, SD-WAN inter-site networking and 32-channel module expansion. Together with the INNOCTRL cloud platform, it unifies cross-region device interconnection and distributed remote O&M.

4-core power

Inter-site networking

Flexible expansion

Bluetooth O&M

Fanless cooling

Multi-protocol

Inter-site Networking
Reshaping Industrial Interconnection

Built-in SD-WAN client supports remote debugging and Layer-2 networking discovery. Together with the INNOCTRL cloud platform, it enables cross-region PLC cascading and data interconnection.

Dual 100M Switch Ports
One Device Drives Many to the Cloud

More than a controller—it is also a gateway. On-site devices are quickly cascaded onto the network, and the controller uniformly builds cross-region secure tunnels for distributed remote O&M.

Multi-protocol Converged Architecture
Cross-region Integrated Deployment

Converges EtherCAT, MQTT, Modbus and SD-WAN protocols, supports flexible 5G/4G and Wi-Fi 5 access, connecting on-site control, cloud data and remote O&M across the full link to build a cloud-edge-device collaborative network.

4-core High-performance
ARM Processor

A low-power embedded architecture optimized for IEC 61131-3-compliant real-time PLC control, ensuring long-term stable operation in industrial sites while balancing low power consumption with real-time response.

Modular Design
Flexible Expansion

High-speed backplane bus, supports up to 32 Class-A IO modules. *Note:
Multi-module configurations require a power coupling module.

Industrial Environmental Adaptability
Stable Wide-temp Low-power Operation

IP20 protection* (installed inside a control cabinet), -20°C~55°C wide-temperature operation, 5%~95% RH moisture protection without condensation.

Aviation aluminum<br/>fanless cooling structure

Aviation aluminum
fanless cooling structure

-20°C~55°C<br/>wide-temperature operation

-20°C~55°C
wide-temperature operation

5%~95% RH<br/>moisture-proof, no condensation

5%~95% RH
moisture-proof, no condensation

Device Interface Definition

Full-domain interfaces, diverse interconnection; fusing wired and multi-band wireless to build cross-region secure networking.

1	4G/5G antenna port, includes 1m suction antenna
2	Wi-Fi antenna port, includes 1m suction antenna
3	DIP switch: RUN/STOP controls host run/stop
4	Detachable panel: for replacing built-in RTC battery
5	X5: Ethernet communication, RJ45 port
6	X4: Ethernet communication, RJ45 port (default IP: 192.168.1.100)
7 8	X3/X2: Ethernet communication, RJ45 port Dual Ethernet ports share a single NIC, supporting network switching
7 8
9	PWR: System power 24V DC, positive
10	System power GND, ground
11	System power GND, ground
12	PWR: System power 24V DC, positive
13	Function status indicator (SF) Green steady: APP connected to controller via Bluetooth Blue flashing: APP connected, in device details page
14	Communication status indicator (COM) Green steady: transmitting signal Yellow steady: receiving signal Yellow-green alternating: simultaneously receiving and sending
15	Device status indicator (STS) Green steady: device normal Yellow steady: no device or device fault
16	Green steady: power on

Industrial-grade Detail Design
Worry-free On-site O&M

Detachable panel

For replacing the built-in RTC battery

DIP switch

Controls host run/stop

Gold-plated connector

Multi-layer gold plating, anti-oxidation
clip-type backplane, more stable

Empowering Diverse Industrial Scenarios

Driving Smart Manufacturing Upgrades
Fully supporting bottom-layer control, distributed acquisition and remote monitoring needs.

Production-line automation & motion control

SoftMotion control · EtherCAT bus · CNC

Powered by strong computing and the EtherCAT real-time bus, it precisely achieves millisecond-level motion control of servo axes, robotic arms and CNC equipment.

Distributed unattended stations

4G/5G access · MQTT reporting · offline cache

Suited for remote water, base-station and other outdoor sites. It reports output and status data in real time via wireless networks combined with an MQTT gateway, with offline cache retransmission to withstand network fluctuations.

Legacy devices: one-to-many to the cloud

100M switch ports · PLC cascading · SD-WAN

Using the built-in dual 100M switch ports, legacy PLCs without inter-site networking capability are cascaded onto the network, and cross-region secure tunnels are built for unified cloud management.

Cross-domain centralized O&M & monitoring

Remote debugging · data dashboard · unified management

Unlocks the full-link data from on-site control to the cloud dashboard. Engineers no longer need to travel frequently—they can view global device status and perform inter-site networking remote debugging from the O&M monitoring center.

1/4

Easier on-site debugging

Auto device discovery & quick binding

Devices are auto-recognized when in range, supporting quick binding in under 5 seconds to greatly boost configuration efficiency.

Real-time device OTA

When a device needs an update, use the App to perform real-time device updates and upgrades.

IP configuration

Conveniently configure the device IP address and perform network debugging from your phone, greatly improving on-site O&M and debugging efficiency.

Debug data logging

Features debug data logging with real-time refresh over a time range and frequency value change recording, convenient for debugging and analysis.

Inter-site networking device configuration

Configure the gateway online from your phone—freely edit names and assign devices to organizations, quickly and conveniently.

*Safety: Before debugging a device via Bluetooth,
make sure the DIP switch is in STOP mode.

Edge Control System
Networking Topology

Expands servo downward via EtherCAT, connects to the cloud upward via MQTT, building a comprehensive control network.

Expansion Modules
Class-A Controller Family SeriesClass-A Expansion Module Models

Digital Modules Product size: 118*85*14.3mm (L*W*D)

16-channel digital output module (PNP)

INN-A3-MODD0016ETP

16-channel digital output 24VDC/PNP transistor

16-channel digital output module (NPN)

INN-A3-MODD0016ETN

16-channel digital output 24VDC/NPN transistor

8-in 8-out module (PNP)

INN-A3-MODD0808ETP

8-channel digital input 24VDC/PNP, 8-channel digital output 24VDC/PNP transistor

8-in 8-out module (NPN)

INN-A3-MODD0808ETN

8-channel digital input 24VDC/NPN, 8-channel digital output 24VDC/NPN transistor

16-channel digital input module

INN-A3-MODD1600END

16-channel digital input 24VDC/PNP or NPN (software switchable)

Analog Modules Product size: 118*85*14.3mm (L*W*D)

8-channel analog input module (voltage)

INN-A3-MODA0800V

8-channel voltage input 0~5/0~10/±5/±10 VDC, 16-bit

8-channel analog output module (voltage)

INN-A3-MODA0008V

8-channel voltage output 0~5/0~10 VDC, 16-bit

8-channel analog input module (current)

INN-A3-MODA0800I

8-channel current input 0~20/4~20/±10 mA, 16-bit

8-channel analog output module (current)

INN-A3-MODA0008I

8-channel current output 0~10/4~20 mA, 16-bit

Function Modules Product size: 118*85*14.3mm (L*W*D)

4-channel serial communication module

INN-A3-MODS04COM

2-channel RS232, 2-channel RS485/RS422 (switchable)

Power coupling module

INN-A3-POWER

Power expansion module for enhancing backplane bus power supply

Edge Controller

The INN-A1-CPUSD-P4 is a programmable edge controller that replaces PLCs, IoT gateways, and remote O&M modules in a single device. With IEC 61131-3-compliant PLC programming, SD-WAN remote networking, and support for up to 32 I/O expansion modules, it integrates seamlessly with the INNOCTRL cloud platform to enable cross-region device interconnection and distributed remote O&M.

Online Purchase

Specifications

Product Name	Edge Controller
Model	INN-A1-CPUSD-P4
Program Capacity	10MB
Data Capacity	20MB
Retentive Memory	32KB (with backup verification)
Real-Time Clock	Supported, built-in replaceable battery
Motion Control Axis Type	EtherCAT servo axes
Local Expansion	Up to 32 Class-A I/O modules (power module required when mounting multiple modules)
Power Terminal Wire Gauge	AWG24~16
Product Certification	CE certification SRRC (refers to the existing type approval of the 4G / Wi-Fi communication module)
Operating Temperature	Horizontal mounting	-20°C – 55°C
Operating Temperature	Non-horizontal mounting	-20°C – 45°C
Storage Temperature	-20°C – 60°C
Ambient Humidity	5% – 95% RH, non-condensing
Installation Altitude	≤ 2000m
Protection Class	IP20
Mounting Method	35mm standard DIN rail
Cooling Design	Natural convection, fanless
Weight	350g
Module Dimensions	L 85mm × W 48mm × H 118mm

EtherCAT	Dual independent Gigabit ports, configurable as EtherCAT interface; only one mode supported at a time (Ethernet or EtherCAT)
Ethernet	Dual independent Gigabit ports; supports TCP / UDP open protocol
Switch Port	Dual 100M switch ports; two ports share a single IP, enabling cascading of other local PLC devices
Backplane Ethernet	Extends 100M to the backplane bus, supports special module expansion
Bluetooth	Supports O&M management, device status monitoring, device maintenance, and interface configuration
Wi‑Fi	Standard	Supports 802.11ac (Wi‑Fi 5)
Wi‑Fi	Band	Dual-band 2.4GHz / 5GHz
Wi‑Fi	Mode	AP mode or STA mode
Wi‑Fi	Wireless Debug	Supported
Wi‑Fi	Cloud Monitoring	Supports cloud-based edge monitoring with remote status, data, and product data reporting
Wi‑Fi	Encryption	WPA / WPA2 / WPA3 encryption
4G/5G	Category	Supports 4G CAT.4 or optional lightweight 5G (RedCap)
4G/5G	Network	Supports all three major carriers
USB OTG	Interface	1× USB 2.0 Type‑C
USB OTG	Role	DRD (Host / Device) dual-role
USB OTG	Function	USB virtual network port for program download

Programming Software	IEC 61131-3-compliant development environment
Programming Languages	IEC 61131-3 standard languages (LD / ST / SFC / FBD / CFC)
Program Upload/Download	Ethernet / USB virtual network port
Firmware Burning	Type‑C
Firmware Update	Ethernet / USB virtual network port
SoftMotion	Motion control development and runtime
CNC	CNC application function development and runtime
EtherCAT Master	EtherCAT master real-time control and communication
Modbus	Modbus master/slave communication integration

MQTT Gateway	Version	MQTT v3.1.1 / v5.0
MQTT Gateway	Connection	Multi-Broker concurrent connections; QoS 0 / 1 / 2
MQTT Gateway	Reporting	String / binary / JSON payloads
MQTT Gateway	Reliability	Automatic reconnection on disconnect, advanced cache and retransmission
MQTT Gateway	Security	TLS encryption, username/password authentication
SD-WAN Remote Networking	Cross-region device interconnection and remote O&M access
SD-WAN (Cascading)	Connect other local PLCs to the SD-WAN tunnel via the dual 100M switch ports for one-to-many remote O&M
Layer-2 Networking	Remote broadcast discovery of on-site PLCs

Input Rated Voltage	24V DC ±10% (21.6V DC–26.4V DC)
Input Rated Current	Without modules	1A
Input Rated Current	Full load	6A (reference value, varies with 4G/5G/Wi‑Fi load)
Bus Output Rated Voltage	5V
Bus Output Rated Current	3A
24V Input Protection	Short-circuit protection

Operating Temperature	Horizontal mounting	-20°C – 55°C
Operating Temperature	Non-horizontal mounting	-20°C – 45°C Note: When the ambient temperature approaches the maximum operating temperature (55°C for horizontal mounting / 45°C for non-horizontal mounting), forced ventilation or air conditioning in the control cabinet is recommended to keep the cooling air inlet/outlet unobstructed.
Storage Temperature	-20°C – 60°C
Ambient Humidity	5% – 95% RH (non-condensing)
Installation Altitude	≤ 2000m
Pollution Degree	II
Protection Class	IP20
Immunity	Power line ±2KV IEC61000-4-4
Overvoltage Category	I
Mechanical Performance	Complies with IEC61131-2, IEC60068-2-6, and IEC60068-2-27
Dielectric Strength	Complies with IEC61131-2
EMC Performance	Complies with IEC61131-2 and IEC61000-4-4
